Our air nozzles, air knives and air blow guns are designed to reduce sound levels and improve the efficiency of blowing with compressed air.
Blowing with compressed air is common in industry when cleaning, drying, cooling, sorting or transporting objects. Silvent air nozzles are used in fixed installations and make efficient use of compressed air. All Silvent air nozzles feature the optimal combination of high blowing force, low energy consumption and low noise levels.
Air knives are most commonly used to blow away liquids, grime, airborne debris, etc. from surfaces or objects. Silvent air knives create a broad and effective flow of air that produces a pneumatic scraping effect without mechanical contact. All Silvent air knives feature the optimal combination of high blowing force, low energy consumption and low noise levels.
Manual blowing with compressed air is common in industry when cleaning, drying or cooling objects. Silvent air blow guns make efficient use of compressed air. All Silvent air blow guns feature the optimal combination of high blowing force, low energy consumption and low noise levels, at the same time as they are ergonomically designed for professional use.
Some industries and processes need more blowing force than a regular air blow gun can generate. Therefore, Silvent has developed air blow guns with high blowing force. The blowing force ranges from twice as strong up to 30 times stronger than a regular air blow gun. All Silvent air blow guns are safe, quiet and efficient, and are developed for professional use.
The noise from compressed air valves is extremely hazardous, but equipping valve discharge ports with pneumatic mufflers often causes operational disturbances. Silvent pneumatic mufflers have integrated warning indicators. The technology basically entails that the pneumatic muffler itself sets the optimal combination of flow capacity and noise suppression thanks to the dynamic internal filter, which subsequently minimizes operational disturbances and eliminates clogging.
To optimize blowing, it is sometimes necessary to be able to make pressure or blowing angle adjustments, for example. In other cases protection against airborne debris may be needed. Silvent has different types of accessories for easily performing various blowing tasks, optimally and safely.
Item number: 70100169110, 70100269110
SILVENT SIS-10: Silvent's pneumatic mufflers are designed to handle sensitive systems with large flows that require minimal flow restriction. The mufflers are compact in size, provide extremely effective noise suppression and feature a built-in warning indicator that immediately shows any increase of backpressure in the system. The unique filter material is divided into numerous "noise traps" or cells and gives extremely good muffling with minimal flow restriction. These pneumatic mufflers are also suitable for continuous flow applications and can be used as a central muffler for several pneumatic valves. A built-in oil trap collects airline oil for draining and prevents oil mist exhaust. The mufflers are available in two sizes, 1 inch and 2 inch, and reduce noise levels 40-45 dB(A). They are supplied with a mounting bracket.
Material specification: EN 10130 DC04 DC01, EN 1.4301, HDPP, NBR, EN 1.4305, CW617N, Zn
The value of the flow applies with continuous operation over a valve. The value of the noise reduction applies with operations over a valve.
See basic information about the technical data. Read more
Read Silvent Group General Instructions for Use before you install the product.
The diagrams show flows and back pressure for different system pressures for each SIS pneumatic muffler. The values in italics state in mm (inches) how much the silencer is triggered. Values range from zero to a maximum recommended triggered mode. where the warning indicator becomes visible.
